Serveredge Cat6a Shielded
  • Serveredge Cat6a Shielded
  • Serveredge Cat6a Shielded
  • Serveredge Cat6a Shielded
Image for illustration purposes, please see product info

Serveredge Cat6a Shielded

Product Features

PRODUCT DESCRIPTION
Serveredge CAT6A 305m Shielded Network Cable - FUTP, Solid, LSZH 23AWG can be used to connect a variety of devices in a high-speed network. The is cable is twisted in pairs, separated by an integrated pair divider. Wrapped around the cable is a layer of PET/AL (foil) for protection from electromagnetic interference (EMI) to reduce noise and increase performance. The outer jacket is LSZH (low smoke zero halogen). It's packaged on a wooden reel with sequential measurement markings on the jacket. The cable meets and exceeds all CAT6A TIA/EIA standards, and drastically reduces both impedance and structural return loss (SRL). The cable is made from the highest quality copper to maximize performance and minimize NearEnd Crosstalk (NEXT).

PRODUCT SPECIFICATION
* Sheath material: Low smoke zero halogen (LSZH)
* Wall thickness of sheath: 0.50mm Rip cord under sheath: Yes
* Binder: Transverse wrapped with a layer of PET/AL
* Insulation material: High-density polyethylene (HDPE) Insulation thickness: 0.283
* Conductor material: Soft annealed bare copper wire Cable construction: 4 twisted pairs stranded together
* Cable colours: Blue, Purple Twisted pair lay length: ?30mm

Guarantee/Warranty
Serveredge products are manufactured at the highest standards using highest quality materials at an affordable price. Serveredge CAT6A UTP cable comes with a 25-year Warranty for that extra piece of mind.

PRODUCT FEATURE
o ISO/IEC 11801 Ed. 2.2 (Class EA)
o IEC 61156-5:2009 (Category 6A)
o ANSI/TIA-568-C.2 (Category 6A)
o Supports all applications designed to operate over Category 6A or lower rated systems
o Sequential measurement markings on jacket
o Come in a variety of colours
o Easy & Effective to use pull box packaging
o Supports up to 10GBASE-T applications
o 25 Year Warrant

Image Code Product Name Save For Later Price Quantity
305m reel Cat6A blue Serveredge PVC solid shielded 10Gb ethernet cable
C6A-305-FUTP-SL-BLU
